International Intergard 7600

SKU
id23981
Parts A & B: UN1263 (Class: 3, Pk Grp: III)
A pure epoxy primer with anti-corrosive properties and overcoating intervals of up to 6 months.
Available in 20 Litres
From £319.08 £265.90
In stock
Only %1 left
Product Description

International Intergard 7600 is a pure epoxy universal primer with good abrasion resistance and anti-corrosive properties, and is suitable for application at low temperatures.

Best Uses

Intergard 7600 can be used in ballast tanks, outer hull, cofferdams, void spaces, topsides, decks, cargo holds and crude oil tanks.

It is suitable for use at newbuilding, with controlled cathodic protection, Maintenance & Repair or On Board Maintenance.

Application

The recommended application method for this product is Airless Spray. Brush and Roller application is only recommended for use in small areas, and multiple coats may be required to achieve specified film thickness.

Use in accordance with the standard Worldwide Marine Specifications.

Ensure all surfaces are clean, dry and free from contamination. High pressure fresh water wash or fresh water wash, as appropriate, and remove all oil or grease, soluble contaminants and other foreign matter in accordance with SSPC-SP1 solvent cleaning.

Surface Preparations

Newbuilding
Where necessary, remove weld spatter and smooth weld seams and sharp edges. Weld seams and areas of shop primer damage or breakdown should be blast cleaned to Sa2½ (ISO 8501-1:2007) or power tooled to Pt3 (JSRA SPSS:1984). Intact, approved, shop primers must be clean, dry and free from soluble salts and any other surface contaminants. Unapproved shop primers will require complete removal by blast cleaning to Sa2½ (ISO 8501-1:2007). In some cases, sweep blasting to a defined International Paint standard (eg AS2 or AS3) may be acceptable.

Major Refurbishment
Abrasive blast clean to Sa2 (ISO 8501-1:2007). If oxidation has occurred between blasting and application of Intergard 7600, the surface should be re-blasted to the specified visual standard. Any surface defects that are revealed by the blast cleaning process, should be ground, filled, or treated in the appropriate
manner.
Or
International Paint Hydroblasting Standard HB2 where flash rust is no worse than HB2M. Hydroblasting is only recommended for underwater hull, above water or topside areas.
Or
International Paint Slurry Blasting Standard SB2 where flash rust is no worse than SB2M. Slurry blasting is only recommended for underwater hull, above water and topside areas.

Repair / OBM
Consult our Technical Team.

Technical Details

Certificates and Approvals

When used as part of an approved scheme, this product has the following certification:

  • Fire Resistance - Marine Equipment Directive compliant
  • Fire Resistance - Surface Spread of Flame (Exova Warringtonfire)
  • Fire Resistance - Smoke & Toxicity (Exova Warringtonfire)
  • Food Contact - Carriage of Grain (NOHH)

Features and Benefits

  • Universal application
  • Optimised application properties
  • True long overcoating intervals (up to 6 months)
  • Application and fast drying at low temperature down to -5°C
  • IMO PSPC compliant (Water Ballast Tanks)
  • Good abrasion resistance
  • Contains aluminium
  • Simplified block coating procedures
  • Excellent spray ability year round
  • Aids shipyard productivity and allows flexibility in the coating process
  • Single product for year round workability and fast access
  • Aids inspection and working conditions
  • Meets the latest regulatory requirements
  • Enhanced corrosion protection
  • Reduced mechanical damages during construction and in service
  • Enhanced corrosion protection

Technical Info

Components: Two Components
Type: Pure Epoxy Universal Primer
Finish: n/a
Stock Colours:

KUA760-Red Aluminium, KUA761-Red, KUA763-Grey, KUA765-Grey Aluminium, KUA769-Black, KUA766-Off White

Tintable: No
VOC Content: 298 g/lt
Volume Solids: 68% ±2%
Suitable Substrates: Suitable for use with controlled cathodic protection
Application Method: Airless Spray, Brush, Roller
Theoretical Coverage: 5.44 m²/litre at 125µm dft
Wet Film Thickness (WFT): 184µm
Dry Film Thickness (DFT): 125µm
Induction Time: -
Pot Life: 2 hours at 25°C
Touch Dry: 60 minutes at 25°C
Overcoatable: See product data sheet for details
Hard Dry: 3 hours at 25°C
Cleaner / Thinner:

Thinner: International GTA220. Thinning is not normally required

Cleaner: International GTA822

Shelf Life: 12 months from date of production unopened
Packaging: Available in 20 Litres
